Zoom
| PERFORMANCE | |
| Processor |
Intel® Core™ i7-12700H, 14C (6P + 8E) / 20T, P-core 2.3 / 4.7GHz, E-core 1.7 / 3.5GHz, 24MB |
| Graphics |
Intel® Arc™ A370M 4GB GDDR6 |
| Chipset |
Intel® SoC Platform |
| Memory |
1x 16GB SO-DIMM DDR5-4800 |
| Memory Slots |
Two DDR5 SO-DIMM slots, dual-channel capable |
| Max Memory |
Up to 16GB DDR5-4800 |
| Storage |
512GB SSD M.2 2280 PCIe® 4.0×4 NVMe® Opal 2.0 |
| Storage Support |
Up to two drives, 1x 2.5″ HDD + 1x M.2 SSD • 2.5″ HDD up to 2TB • M.2 SSD up to 1TB |
| For installing HDD storage, assembly kits are needed. The kits only come with HDD models. | |
| Card Reader |
No card reader |
| Optical |
DVD±RW |
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC274-CG codec |
| Speakers |
3Wx2 |
| Camera |
5.0MP + IR |
| Microphone |
2x, Array |
| Power Supply |
180W 90% |
| DESIGN | |
| Display |
23.8″ FHD (1920×1080) IPS 250nits Anti-glare, 72% NTSC, Touch |
| Touchscreen |
10-point Multi-touch |
| Keyboard |
Calliope Wireless Keyboard, Black, English (UK) |
| Mouse |
Calliope Wireless Mouse, Black |
| Expansion Slots |
Two M.2 slots (one for WLAN, one for SSD) |
| Case Color |
Raven Black |
| Stand |
Liftable Monitor Stand |
| Mounting |
Supports VESA mount 100mm |
| Form Factor |
AIO (23.8 inches) |
| Dimensions (WxDxH) |
541 x 220 x 482 mm (21.3 x 8.7 x 19 inches) |
| Weight |
Around 7.65 kg (16.9 lbs) |
| CONNECTIVITY | |
| Ethernet |
Integrated 100/1000M |
| WLAN + Bluetooth |
Intel® Wi-Fi® 6 AX201, 802.11ax 2×2 + BT5.1 |
| Rear Ports |
1x USB-C® 2.0 (Supports data transfer, Power Delivery 3.0) |
| 2x USB-C® 3.2 Gen 2 | |
| 1x USB 2.0 | |
| 1x USB 3.2 Gen 2 (Supports smart power-on) | |
| 1x HDMI®-in 1.4 | |
| 1x HDMI®-out 2.1 TMDS | |
| 1x Ethernet (RJ-45) | |
| 1x headphone / microphone combo jack (3.5mm) | |
| Left Ports |
1x USB 3.2 Gen 1 |
| Monitor Cable |
1x USB-C® to USB-A |
| SECURITY & PRIVACY | |
| Security Chip |
Firmware TPM 2.0 integrated in SoC |
| Physical Locks |
Kensington® Security Slot™, 3 x 7 mm |
| Included Upgrade |
1Y Onsite from 1Y Depot WHB (CPN) |
| Other Certifications |
TÜV Rheinland® Flicker Free |
| TÜV Rheinland® Low Blue Light | |
| TÜV Rheinland® Ultra Low Noise | |
